H14W-16T brass horizontal check valve is generally applicable to clean media, should not be used for solid particles and viscosity of the medium. The opening and closing parts rely on the flow of media and the power to open or close, in order to prevent the medium backflow valve called check valve. Check valve belongs to the automatic valve class, mainly used for one-way flow of media on the pipeline, only allows the media to flow in one direction to prevent accidents.
Product Parameters
Product Model | H14W-16T |
Valve Body Material | Brass |
Nominal Pressure | ≤1.6Mpa |
Applicable Media | Water, Gas, Oil, etc. |
Applicable Temperature | ≤120°C |
Product Size Reference
Nominal Diameter | SIZE | L | H |
DN15 | 1/2 | 47 | 46 |
DN20 | 3/4 | 55 | 55 |
DN25 | 1 | 62 | 60 |
DN32 | 1-1/4 | 65 | 74 |
DN40 | 1-1/2 | 67 | 75 |
DN50 | 2 | 81 | 95 |
DN65 | 2-1/2 | 100 | 115 |
DN80 | 3 | 120 | 145 |
